Bone Screw Performance Tester
Bone screw performance tester is a multi-functional integrated high-precision test instrument developed for medical orthopedic bone screw performance testing, which can perform It can perform tests related to driving torque, self-tapping performance, extraction force, torsional performance and insertion force of orthopedic screws. This tester can be widely used in medical device inspection It can be widely used in medical device testing institutions, scientific research institutions and medical device manufacturers.
Feature
● Open structure, friendly human-machine interface operation, multiple groups of curve drawing mode, more clear test process
● Adopt precision differential motor drive, with smoother transmission, lower noise, more accurate positioning and better repeatability of test results
Imported custom-made high-sensitivity load element and imported (TBI) screw ensure accurate displacement
● Professional high performance imported control system to control the coordinated action of double servo motors
● Fully automatic measurement
● Easy to operate, highly simplified control system puts all the tedious settings in the background, one key start
Professional fixture for different testing modes
Built-in special calibration program, easy for measurement and calibration department (third party) to calibrate the instrument
● Support data export and Office software, combined with optimized integrated data processing system
● Diversified functions can be achieved by one machine: pull-out performance, self-working performance, rotating torque, torsional performance, insertion force
Standard
YY 0018-2016、YY/T 1504 、YY/T 1505 、YY/T 1506、YY 0315-2016 、YYT 0119.2-2014
ASTM F543 【Standard Specification and Test Methods forMetallic Medical Bone Screws】
Parameter
Test range | 20Kg |
Pull-out force measurement range | 200Kg |
Torque range | 0-3Nm |
Precision | 0.5 Class |
Spin-in and spin-out load | ≤11.17N |
Self-tapping axial compression load | 2N/s |
Test stroke | 300mm |
Resolution | 0.01N/0.001Nm |
Test Mode | Drive torque, self-tapping performance, torsional performance, pull-out, insertion force |
Test speed | 0.5-200mm/min,0.5~30r/min |
Size | 470(L) X440(B) X1000(H) mm |
Power | 220V50Hz |
