Medical Device Flow Tester

WY-008 Medical Device Flow Tester

The WY-008 Medical Device Flow Tester, developed by Vieleader (Jinan) Instrument Co., Ltd., is a professional instrument for testing the flow performance of medical consumables. It features high accuracy, easy operation and standard compliance, suitable for R&D and quality inspection of medical devices.

Main Applications

It accurately measures flow rate, pressure and testing time of infusion sets, blood transfusion sets, catheters, infusion needles, anesthetic filters and other medical consumables. It complies with GB, YY, ISO and ASTMstandards, ensuring safe and stable fluid delivery in clinical use. It is widely used in product research, quality control and registration testing.

Core Parameters

• Pressure range: 10 kPa ~ 200 kPa (up to 300 kPa optional); accuracy: ≤ ±2.5%

• Test time: 5 s ~ 99.9 min; time error: ≤ ±1 s

• Display: 7-inch industrial capacitive touch screen

• Data output: built-in printer for automatic test reports

• Size & weight: 400×270×300 mm, about 10 kg, compact and portable

• Control system: PLC control, stable performance, supporting remote upgrade

Key Advantages

1. Easy operation: intuitive touch menu, no professional training required

2. Full compliance: preset test modes for domestic and international certifications

3. Reliable data: high-precision sensors, traceable test results

4. Permission management: multi-level access, ideal for laboratories and production QC

Overview

The WY-008 is a cost-effective flow testing solution. With stable performance, high precision and simple operation, it helps manufacturers complete flow tests and compliance verification efficiently.
