WY‑002 Rigidity Test for Hypodermic Needle Cannulas
2026-03-17 16:34Model: WY-002 Medical Needle Rigidity Tester
I. Product Overview
Core Positioning
Applicable Objects: Disposable sterile injection needles, prefilled syringe needles, infusion needles, blood collection needles and other types of medical stainless steel rigid needles.
Application Scenarios: Quality control of medical device manufacturers, third-party testing institutions, drug inspection institutes, research and development verification of scientific research colleges and universities.
Compliance Cornerstone: Strictly comply with international and domestic authoritative standards such as ISO 9626:2016, GB 18457-2015, GB 15811-2016, meeting the access requirements of global markets.
II. Core Technical Parameters (Foreign Trade Version)
III. Core Product Advantages (Foreign Trade Selling Points)
1. International Standard Compliance, Global Accessibility
Fully compliant with the international standard ISO 9626:2016 (equivalent to GB 18457), the testing method and data are globally recognized, helping customers' products pass international certifications such as CE and FDA smoothly.
Built-in standard test procedures, one-key call, no complex parameter setting required, ensuring highly consistent test results among different laboratories and operators.
2. High Precision and High Stability
Adopting high-precision force sensor and micron-level displacement sensor, the measurement accuracy of force value and deflection is far higher than the standard requirements, providing solid data support for product quality.
High-rigidity mechanical structure and precision ball screw drive, no drift during long-term operation, ensuring the stability of millions of tests.
Test Application
| Item | English |
|---|---|
| Basic Application | Applicable for the puncture force testing of various injection needles. |
| Extended Application | Puncture force testing of rubber stoppers. |
Product Parameters
| Item | Specification |
|---|---|
| Tube Wall | Normal wall, Thin wall, Ultra-thin wall, Extra-thin wall (optional) |
| Nominal Specification | 0.18~3.4 mm |
| Testing Range | 0~10 N |
| Testing Accuracy | ±0.5% FS (Full Scale) |
| Testing Speed | (100±5) mm/min |
| Simulated Skin | Polyurethane film |
| Printing Function | Print test data, average puncture force and deviation each time |
| Dimensions | 400 mm (L) × 270 mm (W) × 360 mm (H) |
| Net Weight | 12 kg |
